Design of a Power Electronic Transformer Structure Based on Multi-Port Converters with Integrated Energy Storage Capability
H. Kavosh
1
(
Depف.of Elec. and Comp. Eng., Jundi-Shapur University of Technology, Dezful, Iran.
)
M. Saradarzadeh
2
(
Depف.of Elec. and Comp. Eng., Jundi-Shapur University of Technology, Dezful, Iran.
)
Keywords: Multi-active bridge, power electronics transformer, energy storage, single phase shift.,
Abstract :
Power Electronic Transformers (PETs) have emerged as promising alternatives to conventional Line Frequency Transformers (LFTs) in modern power systems. For high-power and high-voltage applications, modular configurations such as Cascaded H-Bridge (CHB) structures are widely recognized as effective PET design solutions. However, existing PET topologies, most commonly based on Dual Active Bridge (DAB) converters, suffer from significant drawbacks, including low-frequency distortion power in DC-link capacitors and degraded performance under fault conditions.
To overcome these limitations, this paper introduces several multi-port converter-based PET architectures. By employing multiple five-port active bridge converters in conjunction with supercapacitors and an advanced control strategy for inter-port power management, the proposed PET achieves enhanced dynamic performance and fault-tolerant operation at both medium-voltage (MV) and low-voltage (LV) levels. Conceptual design and comprehensive simulation studies conducted in Matlab/Simulink confirm the effectiveness and robustness of the proposed topologies.
